SF Single Layer Flexible Mounting System

Short Description:

In recent years, with the development of the photovoltaic industry, land and roof resources have gradually decreased. Limited by the traditional support form, the undulating mountains, fish ponds with deep water levels, and sewage treatment plants with large spans cannot be fully utilized. The emergence of flexible bracket has solved the above problems, which is a new trend in the application of photovoltaic bracket.

Send email to us

Product Detail

Product Tags

SF Single Layer Flexible Mounting System

Product Highlights

· Larger Span:it generally has a span of half string (15-20m).

· High Clearance:normally under 6 meters

· Less Foundations:Save about 20% compared with conventional fixed structure foundations (according to the array design)

· Less steel:30% less than the fixed structure (fixed structreabout 20 tons)

· Wider terrain adaptability:applicable for theinstallation in irregular mountainous terrain, hills,deserts, ponds etc.

· Simple structure, once tensioning, convenient construction.

· In some environments,wind cables should be used to improve wind resistance.

· High cost performance, improve the utilization rate of land.

Technical parameter

Technical Details
Installation	Ground
Foundation	PHC/Cast-in-place Pile
Modules Layout	Single Row in Portrait
Single span	≤20 m
Wind Load	0.45KN/㎡ (Adjustable according to the project
Snow Load	0.15KN/㎡ (Adjustable according to the project)
Tilt Angle	<30°
Standards	GB 50009-2012、GB 50017-2017、NB/T 10115-2018、JGJ257-2012、JGJT 497-2023
Material	Anodized Aluminum AL6005-T5, Hot Dip Galvanized Steel, Zn-Al-Mg pre-coated steel,Stainless Steel SUS304
Warranty	10 Years Warranty
